TPA-TRM-3-2A-3 - OBSOLETE, REPLACEMENT 20182 TRM4 2A - ARDETEM Schweiz  Verkauf

20085

TPIs 50 N F/I-Wandler Ethernet einkanaliger Frequenzwandler Eingang: Kontakt, Logik, Namur, NPN/PNP Analogausgang: 0 - 20 mA, 0 - 10 V PC-programmierbar mit software SUPERVISION über USB-Anschluss oder über Ethernet

20090

TPIs 12 Messumformer mit Prozesseingang 1 Analogausgang Messumformer mit Prozesseingang im 7,2 mm-Gehäuse Eingang: mA; mV; V 1 Analogausgang: 0 - 10 V; 0/4 - 20 mA aktiv Spannungsversorgung: 24 VDC PC-programmierbar mit Software SUPERVISION über USB-Anschluss

20164 PECA11D2RF

Universal phase analyzer Disturbancen AC universal analyzer for interference 3 or 4 wire three-phase systems, reading balanced and unbalanced networks 2 R-2 relay outputs NO F - Modbus TCP Ethernet output Display: 96 x 96 with backlight Display up to 50 parameters Upper and lower wave analysis 2 programmable voltage ranges Un = 100V LN / LN 173V LL and 330V / 600V LL 2 programmable current ranges 0 to 1 A and 0 .5 A Universal Power Supply AC / DC 40ms response time (2 periods) Standard output RS 485 Modbus Customs tariff number: 9030390090 Country of origin: France / EU

20182 TRM4 2A

TRM4 2A Universal three-phase analyzerUniversal three-phase analyzer3 or 4 wire three-phase systems, readingbalanced and unbalanced networksInput: Voltage 0 3 .150 VAC, 0 ... 500 VACOutput: 3 Current 0 .1 0 .5 A and A (automaticswitching)Universal power supply AC / DCResponse time 40ms (two periods)Outputs 2 x analog bipolar)PC programmable with software SUPERVISIONPossible options:Up to 5 programmable analog0 ... 20mA, 4 ... 20mA, 0 ... 5 mA two of thesebipolar)4 output relays without analog output, or 2Relay outputs with max. 2 analog outputsEthernetProfibus DP• Overload: 10 times the rated current for 10 seconds• 50 times rated current (EDF standard) for 60 ms

20223 DIP40 0A1 R

Anzeige mit bidirektionalem Prozesseingang, Analogausgang + 2 Relais Digitalanzeige 48 x 96mm, 4 digits bidirektionaler Prozesseingang (mA, mV, V) mA-Ausgang aktiv und 2 Relais Universal-Spannungsversorgung 24 - 240VAC/DC programmierbar über Fronttasten oder mittels PC und software SUPERVISION

20224 DIP402 R

Anzeige 48 x 96mm mit Universaleingang+ 2 Relais im Ausgang Digitalanzeige 48 x 96mm, 4 digits Universaleingang mA, V, Temp. Potentiometer, Widerstand 2 Relais im Ausgang Universal-Spannungsversorgung 24 - 240VAC/DC programmierbar über Fronttasten oder mittels PC und software SUPERVISION

ART.NR. 20009

Supervision programming tool Software to program the ARDETEM Devices including USB interface and connection cables

ART.NR. 20012

μCONSOLE LCD Display / Removable programming unit for all Ardetem devices

ART.NR. 20017

TPI 10 AR universal transmitter with Analog output and 2 relays TPI 10 AR Universal Input: current, voltage, temperature resistance Output: Analog (current / voltage), 2 relays Programmable with display / PC Universal power supply: 20-300 VDC / VAC

DIP400 with tropicalization option.

digitale Anzeige universelle Stromversorgung

PECA 30 ES 5 A2

elektrischer Netzwerkanalysator

PECA11

ELECTRICAL MEASURE CENTRAL Current input: 1A and 5 A AC Voltage input: 175 V and 600 V AC For all network types Graphical LCD with rear-lighting 28 measurable parameters: 3U, 3V, 3I, cos, f, F, P, Q, S, E... Display of the energies on 8 digits on a single line with automatic switching to the upper unit Automatic correction of the wiring Output: RS 485 Modbus/Jbus Universal power supply; 20 to 270 vac and 20 to 300 vdc Format: 96x96mm

PECA11 DC 15-50

Measurement of DC signals - Dimensions 96x96x108mm -LCD ,DC networks

PECA11 DC130 1

PECA3001

Signalanalysator für elektrische Netzwerke

SP 125 ARD

ISOLATIONS-STANDARD-DETEKTOR

TAI 60

Programmierbarer Transmitter

TMA-HI

AC MEASURE TRANSMITTERS - high insulation 4KV. Input 0-5A and standard output 4-20mA Galvanic partition: 4Kv Accuracy rating: <0.3% Power supply: 20 to 270 Vac and 20 to 300 Vdc

TMP

DC MEASURE TRANSDUCER / DC MESSUMFORMER Input / Eingang: 0-1000 VDC Output / Ausgang: 4-20 mA Galvanic partition / galvanische Trennung: 2KV Accuracy rating / Genauigkeit: 0.2% For DIN rail mounting / Für Montage auf DIN Schiene Power supply / Spannungsversorgung: 20 ... 270 Vac & 20 ... 300 Vdc

TMP-HI-2

TMP-HI-2 EXCITATION CURRENT TRANSDUCER ,I/P : 75A/100mV O/P : 4-20 mA AUX : 90-270 VAC, 88-350 VDC 2-WIRE SENSOR

TMvP-HI-3-SP12/05

Universeller Strom- und Spannungstransmitter

TPI 302 SERIAL:0302-388- OBSOLETE, REPLACED BY TPI400

power converter

TPI400 A

PROGRAMMABLE CONVERTER Input: mA,mV,V. Bidirectionnal current and voltage input up to +/- 300 V dc Accuracy rating: 0.1% Programmable scale factor Supply for 2-wire sensor Insulated analog output (voltage or current) For DIN rail mounting Programmable by software or µconsole (optional) Universal power supply: 20 to 270 vac and 20 to 300 vdc

TRM 2

A three-phase analyzer for synchronous networks Three-phase analyzer for synchronous networks DIN-rail mounting AC indicator for exchange or Three-phase systems Voltage input 0 1 .150 VAC, 0 ... 600 VAC + 20% 1 Current input 0 .1 0 .5 A or A (automatic switching) Spanungsversorgung Universal AC / DC Response time 40ms (two periods) 1 analogue output Programmable with Display (LCD μCONSOLE) or PC

USB-SER

Strect 20

Versorgung: 90 ÷ 270 VAC; 8÷350VDC, Reichweite: 150/500V & 1A÷5A

TMP-HI

Transmitter
